Epson OmniLink TM-T88VII Direct Thermal Printer - Monochrome - Receipt Print - Ethernet - USB - Yes - With Cutter - Black - 19.69 in/s Mono - 180 dpi (C31CJ57032)
Epson OmniLink TM-T88VII Direct Thermal Printer - Monochrome - Receipt Print - Ethernet - USB - Yes - With Cutter - Black - 19.69 in/s Mono - 180 dpi (C31CJ57032)
EPSON TM-T88VII-032 THERMAL RECEIPT PRINTER WITH
Manufacturer Part Number: C31CJ57032
CPN:EPSON TM-T88VII-032 THERMAL RECEIPT PRINTER WITH
MANUFACTURER NAME: Epson
MANUFACTURER PART NUMBER: C31CJ57032
UPC EAN CODE:
LANGUAGE: EN
MARKET:US
Epson OmniLink TM-T88VII 180 x 180 DPI Wired Thermal POS printer
Brand: Epson
Product Name: OmniLink TM-T88VII
Article code: C31CJ57032
- Thermal POS printer
- 180 x 180 DPI
- Connectivity technology: Wired
- USB port Ethernet LAN
- Built-in barcodes
- Black
- 3.75 lbs (1.7 kg)
Specs
Printing
Maximum resolution
Maximum printing resolution.
180 x 180 DPI
Print speed
The maximum speed at which a printer can print.
500 mm/sec
Character size
0.0555 x 0.133" (1.41 x 3.39 mm)
Printing characters
Text, Graphic, Barcode, 2D barcode
Character sets
ANK
Print technology
Indicates the method used to print by this product.
Thermal
Type
Characteristics of the device.
POS printer
Paper handling
Printing media thickness
Physical thickness of media (paper or film) expressed in mils and microns.
48 - 80 µm
Maximum roll diameter
The maximum size of roll that can be used, measured by the diameter which is the distance from one side to the other with a straight line passing through the centre of the roll.
3.27" (8.3 cm)
Supported paper width
80 mm
Media thickness
48 - 80 mm
Ports & interfaces
USB port
The device features a socket into which a USB cable can be plugged.
USB connector
What type of USB connector is built into the device.
USB Type-A / USB Type-B
Parallel connector
Connectivity technology
The technology that enables connectivity of the device, e.g. wired or wireless.
Wired
Optional connectivity
Wireless LAN
Network
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Ethernet LAN data rates
The different speed levels of the Ethernet LAN connection.
10, 100 Mbit/s
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Features
Built-in barcodes
CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, UPC-A, UPC-E
Sound pressure level (printing)
52 dB
Sound pressure level (standby)
52 dB
Mean time between failures (MTBF)
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
360000 h
Autocutter durability
3 million cuts
Paper save function
Print head life
200 km
Mounting position
Horizontal/Vertical
Wall mountable
The product can be mounted on (attached to ) a wall.
Built-in sensors details
Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor
Certification
CE
Design
Product color
The colour e.g. red, blue, green, black, white.
Black
Power
Power source type
What the power source is.
USB
Power consumption
27900 mA
Power consumption (standby)
1400 mA
Power consumption (standby)
The amount of electricity that is consumed when the product is on standby.
1.4 W
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
5 - 45 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
10 - 90%
System requirements
Pre-installed software
List of pre-installed software for the product; including manufacturer; coined name and modules where applicable; or generic descriptor
Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print
Weight & dimensions
Width
The measurement or extent of something from side to side.
5.71" (145 mm)
Depth
The distance from the front to the back of something.
7.68" (195 mm)
Height
The measurement of the product from head to foot or from base to top.
5.83" (148 mm)
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
3.75 lbs (1.7 kg)
Packaging data
Quantity per pack
1 pc(s)
Package width
The distance from one side of the packaging to the other.
7.68" (195 mm)
Package depth
The distance from the front to the back of the packaging.
9.25" (235 mm)
Package height
The distance from the top to the bottom of the packaging.
10.2" (260 mm)
Package weight
Weight of the packaged product in gram.
5.95 lbs (2.7 kg)
Print technology
Column capacity
42/56
Logistics data
Pallet weight (UK)
0 oz (0 g)
Quantity per pallet
Quantity of a single product per pallet. If more than one product is packed per carton; this is the number of products (not number of cartons) per shipping pallet.
112 pc(s)
Pallet weight
0 oz (0 g)
Quantity per pallet (UK)
168 pc(s)
Technical details
Changeable interface
Lifetime
20000000 lines
Other features
Buffer size
The buffer is a temporary memory area in which data is stored while it is being processed or transferred, especially one used while streaming video or downloading audio. The buffer size is usually measured in MB (megabytes) or KB (kilobytes).
4 KB
Mean cycles between failures (MCBF)
70000000
| General Information: | |
| Manufacturer | Epson Corporation |
| Manufacturer Part Number | C31CJ57032 |
| Manufacturer Website Address | http://www.epson.com |
| Brand Name | Epson |
| Product Line | OmniLink |
| Product Model | TM-T88VII |
| Product Name | OmniLink TM-T88VII Direct Thermal Printer |
| Product Type | Direct Thermal Printer |
| Technical Information: | |
| Recommended Use | Receipt Print |
| Print Color Capability | Monochrome |
| Maximum Mono Print Speed | 19.69 in/s |
| Maximum Print Resolution (dpi) | 180 |
| Interfaces/Ports: | |
| USB Host | Yes |
| USB | Yes |
| Network & Communication: | |
| Ethernet | Yes |
| Ethernet Technology | Ethernet |
| Cutter: | |
| Cutter | Yes |
| Cutting Method | Automatic |
| Media Types & Handling: | |
| Media Type | Receipt |
| Physical Characteristics: | |
| Product Color | Black |
| Weight (Approximate) | 5 lb |
| Miscellaneous: | |
| Country of Origin | United States |
731.14 $
